1. redis 基礎結構

2. 1.1 redis 序列化

Redis本身沒有辦法支持存儲對象類型的接口,只能存儲字節類型的數據,因此redis在存儲任何類型的數據結構時都要先將其序列化.

當一個類實現了Serializable接口(該接口僅為標記接口,不包含任何辦法定義),表示該類可以序列化.序列化的目的是將一個實現了Serializable接口的對象轉換成一個字節序列,可以.把該字節序列保存起來(例如:保存在一個文件里),以后可以隨時將該字節序列恢復為原來的對象.甚至可以將該字節序列放到其他計算機上或者通過網絡傳輸?shù)狡渌嬎銠C上恢復,只要該計算機平臺存在相應的類就可以正常恢復為原來的對象.

快速序列化工具介紹：

公司封裝的序列化和反序列化工具：org.springframework.core.serializer.support. DeserializingConverter類的convert辦法

但實際底層最后用的還是Java的ByteArrayInputStream byteStream = new ByteArrayInputStream(source);

ObjectInputStream objectInputStream = new ObjectInputStream(inputStream);

ObjectInputStream. readObject()

1.2五種數據結構應用 String ,hash,set ,list

參考: zhuanlan.zhihu.com/p/21368183?refer=zhangtielei

blog.csdn.net/a809146548/article/category/2915269/2

上面四種數據結構的實現分別是：

1). Dict ：是key和value映射關系的數據結構,基于hash表的算法采用某個哈希函數從key計算得到在哈希表中的位置,如圖：

2). Quicklist : 雙向鏈表 ,quicklist的每個節點都是一個ziplist .雙鏈表,這是在存儲效率和查詢時間上的折中設計.因為其在每個節點上除了要保留數據之外,還要額外保留兩個指針；其次,雙向鏈表的各個節點是單獨的內存塊,地址不連續,節點多了容易產生內存碎片.所有其長度的設計需要根據不同情況具體定義,

Redis提供了一個配置參數list-max-ziplist-size

· -5: 每個quicklist節點上的ziplist大小不能超過64 Kb.(注：1kb => 1024 bytes)

· -4: 每個quicklist節點上的ziplist大小不能超過32 Kb.

· -3: 每個quicklist節點上的ziplist大小不能超過16 Kb.

· -2: 每個quicklist節點上的ziplist大小不能超過8 Kb.(-2是Redis給出的默認值)

如圖：

1.3 redis的持久化

作用主要是防止redis應用掛掉之后重啟服務重新加載redis內存數據庫.

1.3.1 第一種是快照形式的：依照改動頻率存儲,存儲規則：save N M表示在N秒之內,redis至少發生M次修改則redis抓快照到磁盤.這樣的好處是保證大部分數據完整,效率高,但是數據不是完全同步的,在redis應用停掉后最近的數據會丟失.

第二種是AOF持久化：可以做到每次修改都記錄到aof文件,但這樣影響效率,也可以每秒同步變化的數據到aof文件,這樣不影響效率但有可以會丟失一秒內的數據.

2.redis 驚群處理

2.1 方案的由來

Redis的緩存數據庫是為快速響應客戶端減輕數據庫壓力的有效手段之一,其中有一種功能是失效緩存,其優點是可以不定期的釋放使用頻率低的業務空間而增加有限的內存,但對于同步數據庫和緩存之間的數據來說需要面臨一個問題就是：在并發量比較大的情況下當一個緩存數據失效之后會導致同時有多個并發線程去向后端數據庫發起哀求去獲取同一業務數據,這樣如果在一段時間內同時生成了大量的緩存,然后在另外一段時間內又有大量的緩存失效,這樣就會導致后端數據庫的壓力陡增,這種現象就可以稱為“緩存過期產生的驚群現象”!

2.2 處理邏輯

緩存內真實失效時間time1

緩存value中存放人為失效時間戳 ：time2 ( time2 永遠小于time1 )

緩存value對應的lock鎖 (便是一個與value 對應的 另一個key),主要用于判斷是第幾個線程來讀取redis的value

當把數據庫的數據寫入緩存后,這時有客戶端第一次來讀取緩存,取當前系統時間:system_time 如果system_time >= time2 則認為默認緩存已過期(如果system_time < time1 則還沒真實失效 ),這時再獲取value的lock鎖,調用redis的incr函數(單線程自增函數)判斷是第幾個獲取鎖的線程,當且僅當是第一個線程時返回1,以后都逐漸遞增.第一個拜訪的線程到數據庫中獲取最新值重新放入緩存并刪除lock鎖的key,并重新設置時間戳；在刪除lock之前所有拜訪value客戶端線程獲取lock的value都大于1,這些線程仍然讀取redis中的舊值,而不會集中拜訪數據庫.

2.3 偽代碼

private long expirt_time = 1000 * 40 ;//人為過期時間

private long time = 1000 * 60;//一分鐘

private long second = 60 * 6;//六分鐘

KooJedisClient client = SpringContextUtils.getBean("redisClient", KooJedisClient.class);

private final String user_key = "USER_REDIS";

private final String user_key_lock = "USER_REDIS_lock";

public void setExpireTime( HttpServletRequest request ){

String userId = request.getParameter( "userId");

//數組里存放：1：真實value ,2：過期時間

String key = org.apache.commons.lang3.StringUtils.join(new Object[]{user_key, userId});

String[] info = client.get( key , String[].class);

long nowTime = System.currentTimeMillis();

if( null != info ){

long expireRealTime = new Long( info[1] );

//如果已過期并且是第一個拜訪的線程

if( nowTime >= expireRealTime ){

Long lockNum = client.incr( user_key_lock+userId ); // 可以實現原子性的遞增,可應用于高并發的秒殺活動、分布式序列號生成等場景

if( ( lockNum == 1 || lockNum == null )){

//重新從數據庫獲取

User user = teacherDataMaintain.findUserInfo(new Integer(userId));

info[ 0 ] = user.getUserName();

info[ 1 ] = org.apache.commons.lang3.StringUtils.join(new Object[]{(nowTime + expirt_time), ""});

client.setex( key ,60, info );//六分后過期

client.del( user_key_lock+userId );

}else{

System.out.println( "緩存過期但不是第一個線程,返回舊值" );

}

}else{

//返回緩存中舊值

System.out.println( "緩存未過期" );

}

}else{

User user = teacherDataMaintain.findUserInfo(new Integer(userId));

String[] userInfo = { user.getUserName() ,(nowTime + expirt_time ) + "" };

client.setex( key ,60, userInfo );//過期

}

}

3.redis 分布式鎖應用

3.1 分布式鎖主要是解決分布式環境對共享資源的同步拜訪

在但進程的環境下程序上完全可以用synchronized同步鎖來限制多線程對共享資源的拜訪,但在分布式環境下同步鎖無法控制不同進程之間的線程,這種情況下就需要找一種單進程可串行處理的“鎖”,redis 就是其中的一種選擇,

3.2. 應用場景：

例如：秒殺,一個官網售賣的視頻課程,這個課程只有若干個名單可以售賣,每個課程對應具體的庫存,怎樣讓每個客戶端獲取課程的的庫存都是準確實時的,

Redis 緩存中與數據庫的庫存在秒殺前是一樣的,當秒殺開始的時候,同一時間點會有很多客戶端拜訪緩存和數據庫,不同的進程同時拜訪緩存或者數據庫,當緩存中的數據變化后并且沒被修改之前有可能又被另一個線程獲取,數據有可能出現臟讀和數據被覆蓋的可能.(臟讀 < 不可重復讀 < 幻讀)

3.3 解決方法：

對共享資源的操作要是互斥且良性的競爭,即在分布式條件下怎樣做到一次只能有一個線程來處理共享資源?且線程之間不會出現死鎖的情況.

3.3.1 幾個基本的函數：

Setnx key value ：如果沒有key 則可以獲得鎖并返回1 ,如果已存在key 則不做操作并返回0 .

Getset key value ：設置value ,并返回key的舊值,若key不存在則返回null

Get key :

3.3.2 死鎖

Setnx是單線程處理的,但仍有可能出現死鎖

Eg：thread0 操作超時了,但它還持有著鎖,thread 1 和thread 2 讀取lock.foo檢查時間戳,然后發現超時了；

thread 1 發送DEL lock.foo；

thread 1 發送SETNX lock.foo 并且成功了；

thread 2 發送DEL lock.foo；

thread 2 發送SETNX lock.foo 并且成功了.

這樣一來,thread 1、thread 2都拿到了鎖!鎖平安性被破壞了!

3.3.3 辦理死鎖

1. thread 3 發送SETNX lock.foo 想要獲得鎖,由于thread 0 還持有鎖,所以Redis返回給thread 3 一個0；

2. thread 3 發送GET lock.foo 以檢查鎖是否超時了,如果沒超時,則等待或重試；

3. 反之,如果已超時,thread 3 通過下面的操作來嘗試獲得鎖：

   GETSET lock.foo <current Unix time + lock timeout + 1>

   通過getSet,thread 3 拿到的時間戳如果仍然是超時的,那就說明,thread 3 如愿以償拿到鎖了.

4. 如果在thread 3 之前,有個叫thread 4 的客戶端比thread 3 快一步執行了上面的操作,那么thread 3 拿到的時間戳是個未超時的值,這時,thread 3 沒有如期獲得鎖,需要再次等待或重試.把穩一下,盡管thread 3 沒拿到鎖,但它改寫了thread 4 設置的鎖的超時值,不過這一點非常微小的誤差帶來的影響可以忽略不計.

3.4 偽代碼

public synchronized boolean acquire(Jedis jedis, String lockKey, long expires) throws InterruptedException {

int timeoutMsecs = 10 * 1000;

int timeout = timeoutMsecs;

while ( timeout >= 0 ) {

String expiresStr = String.valueOf( expires ); //鎖到期時間

if ( jedis.setnx( lockKey, expiresStr ) == 1 ) {

// lock acquired

return true;

}

String currentValueStr = jedis.get(lockKey); //redis里的時間

if(currentValueStr!=null&& Long.parseLong(currentValueStr) < System.currentTimeMillis()) {

//判斷是否為空,不為空的情況下,如果被其他線程設置了值,則第二個條件判斷是過不去的

// lock is expired

//Getset命令用于設置指定key的值,并返回key舊的值.

String oldValueStr = jedis.getSet(lockKey, expiresStr);

//獲取上一個鎖到期時間,并設置現在的鎖到期時間

//只有一個線程才能獲取上一個線上的設置時間,因為jedis.getSet是同步的

if (oldValueStr != null && oldValueStr.equals(currentValueStr)) {

//如過這個時候,多個線程恰好都到了這里,但是只有一個線程的設置值和當前值相同,他才有權利獲取鎖

// lock acquired

return true;

}

}

timeout -= 100;

Thread.sleep(100); //每100毫秒重試一次,直至timeout用盡

}

//Expire命令用于設定鍵有效期.到期時間后鍵不會在Redis中使用.

return false;

}

以下是redis的配置文件Redis.conf的參數說明：

# By default Redis does not run as a daemon. Use 'yes' if you need it.

# Note that Redis will write a pid file in /var/run/redis.pid when daemonized.

#Redis默認不是以守護進程的方式運行,可以通過該配置項修改,使用yes啟用守護進程

daemonize no

# When running daemonized, Redis writes a pid file in /var/run/redis.pid by

# default. You can specify a custom pid file location here.

#當 Redis 以守護進程的方式運行的時候,Redis 默認會把 pid 文件放在/var/run/redis.pid

#可配置到其他地址,當運行多個 redis 服務時,必要指定不同的 pid 文件和端口

pidfile /var/run/redis.pid

# Accept connections on the specified port, default is 6379.

# If port 0 is specified Redis will not listen on a TCP socket.

#端口

port 6379

# If you want you can bind a single interface, if the bind option is not

# specified all the interfaces will listen for incoming connections.

#指定Redis可接收哀求的IP地址,不設置將處理所有哀求,建議生產環境中設置

# bind 127.0.0.1

# Close the connection after a client is idle for N seconds (0 to disable)

#客戶端連接的超時時間,單位為秒,超時后會關閉連接

timeout 0

# Set server verbosity to 'debug'

# it can be one of:

# debug (a lot of information, useful for development/testing)

# verbose (many rarely useful info, but not a mess like the debug level)

# notice (moderately verbose, what you want in production probably)

# warning (only very important / critical messages are logged)

#日志記錄等級,4個可選值

loglevel notice

# Specify the log file name. Also 'stdout' can be used to force

# Redis to log on the standard output. Note that if you use standard

# output for logging but daemonize, logs will be sent to /dev/null

#配置 log 文件地址,默認打印在命令行終端的窗口上,也可設為/dev/null屏蔽日志、

logfile stdout

# Set the number of databases. The default database is DB 0, you can select

# a different one on a per-connection basis using SELECT where

# dbid is a number between 0 and 'databases'-1

#設置數據庫的個數,可以使用 SELECT 命令來切換數據庫.

databases 16

#

# Save the DB on disk:

#

# save

#

# Will save the DB if both the given number of seconds and the given

# number of write operations against the DB occurred.

#

# In the example below the behaviour will be to save:

# after 900 sec (15 min) if at least 1 key changed

# after 300 sec (5 min) if at least 10 keys changed

# after 60 sec if at least 10000 keys changed

#

# Note: you can disable saving at all commenting all the "save" lines.

#設置 Redis 進行數據庫鏡像的頻率.保留數據到disk的策略

#900秒之內有1個keys發生變化時

#30秒之內有10個keys發生變化時

#60秒之內有10000個keys發生變化時

save 900 1

save 300 10

save 60 10000

# Compress string objects using LZF when dump .rdb databases?

# For default that's set to 'yes' as it's almost always a win.

# If you want to save some CPU in the saving child set it to 'no' but

# the dataset will likely be bigger if you have compressible values or keys.

#在進行鏡像備份時,是否進行壓縮

rdbcompression yes

# The filename where to dump the DB

#鏡像備份文件的文件名

dbfilename dump.rdb

# The working directory.

#

# The DB will be written inside this directory, with the filename specified

# above using the 'dbfilename' configuration directive.

#

# Also the Append Only File will be created inside this directory.

#

# Note that you must specify a directory here, not a file name.

#數據庫鏡像備份的文件放置的路徑

#路徑跟文件名分開配置是因為 Redis 備份時,先會將當前數據庫的狀態寫入到一個臨時文件

#等備份完成時,再把該臨時文件替換為上面所指定的文件

#而臨時文件和上面所配置的備份文件都會放在這個指定的路徑當中

#默認值為 ./

dir /var/lib/redis/

# Master-Slave replication. Use slaveof to make a Redis instance a copy of

# another Redis server. Note that the configuration is local to the slave

# so for example it is possible to configure the slave to save the DB with a

# different interval, or to listen to another port, and so on.

#設置該數據庫為其他數據庫的從數據庫

#slaveof <masterip> <masterport> 當本機為從服務時,設置主服務的IP及端口

# slaveof

# If the master is password protected (using the "requirepass" configuration

# directive below) it is possible to tell the slave to authenticate before

# starting the replication synchronization process, otherwise the master will

# refuse the slave request.

#指定與主數據庫連接時需要的暗碼驗證

#masterauth <master-password> 當本機為從服務時,設置主服務的連接暗碼

# masterauth

# When a slave lost the connection with the master, or when the replication

# is still in progress, the slave can act in two different ways:

#

# 1) if slave-serve-stale-data is set to 'yes' (the default) the slave will

# still reply to client requests, possibly with out of data data, or the

# data set may just be empty if this is the first synchronization.

#

# 2) if slave-serve-stale data is set to 'no' the slave will reply with

# an error "SYNC with master in progress" to all the kind of commands

# but to INFO and SLAVEOF.

#當slave丟失與master的連接時,或slave仍然在于master進行數據同步時(未與master堅持一致)

#slave可有兩種方式來響應客戶端哀求：

#1)如果 slave-serve-stale-data 設置成 'yes'(默認),slave仍會響應客戶端哀求,此時可能會有問題

#2)如果 slave-serve-stale-data 設置成 'no',slave會返回"SYNC with master in progress"錯誤信息,但 INFO 和SLAVEOF命令除外.

slave-serve-stale-data yes

# Require clients to issue AUTH before processing any other

# commands. This might be useful in environments in which you do not trust

# others with access to the host running redis-server.

#

# This should stay commented out for backward compatibility and because most

# people do not need auth (e.g. they run their own servers).

#

# Warning: since Redis is pretty fast an outside user can try up to

# 150k passwords per second against a good box. This means that you should

# use a very strong password otherwise it will be very easy to break.

#設置客戶端連接后進行任何其他指定前需要使用的暗碼

#redis速度相當快,一個外部用戶在一秒鐘進行150K次暗碼嘗試,需指定強大的暗碼來防止暴力破解

# requirepass foobared

# Set the max number of connected clients at the same time. By default there

# is no limit, and it's up to the number of file descriptors the Redis process

# is able to open. The special value '0' means no limits.

# Once the limit is reached Redis will close all the new connections sending

# an error 'max number of clients reached'.

#限制同時連接的客戶數量.

#當連接數超過這個值時,redis 將不再接收其他連接哀求,客戶端嘗試連接時將收到 error 信息

# maxclients 128

# Don't use more memory than the specified amount of bytes.

# When the memory limit is reached Redis will try to remove keys

# accordingly to the eviction policy selected (see maxmemmory-policy).

#

# If Redis can't remove keys according to the policy, or if the policy is

# set to 'noeviction', Redis will start to reply with errors to commands

# that would use more memory, like SET, LPUSH, and so on, and will continue

# to reply to read-only commands like GET.

#

# This option is usually useful when using Redis as an LRU cache, or to set

# an hard memory limit for an instance (using the 'noeviction' policy).

#

# WARNING: If you have slaves attached to an instance with maxmemory on,

# the size of the output buffers needed to feed the slaves are subtracted

# from the used memory count, so that network problems / resyncs will

# not trigger a loop where keys are evicted, and in turn the output

# buffer of slaves is full with DELs of keys evicted triggering the deletion

# of more keys, and so forth until the database is completely emptied.

#

# In short... if you have slaves attached it is suggested that you set a lower

# limit for maxmemory so that there is some free RAM on the system for slave

# output buffers (but this is not needed if the policy is 'noeviction').

#設置redis能夠使用的最大內存.

#達到最大內存設置后,Redis會先嘗試清除已到期或即將到期的Key(設置過期信息的key)

#在刪除時,依照過期時間進行刪除,最早將要被過期的key將最先被刪除

#如果已到期或即將到期的key刪光,仍進行set操作,那么將返回錯誤

#此時redis將不再接收寫哀求,只接收get哀求.

#maxmemory的設置比擬適合于把redis當作于類似memcached 的緩存來使用

# maxmemory <bytes>

# By default Redis asynchronously dumps the dataset on disk. If you can live

# with the idea that the latest records will be lost if something like a crash

# happens this is the preferred way to run Redis. If instead you care a lot

# about your data and don't want to that a single record can get lost you should

# enable the append only mode: when this mode is enabled Redis will append

# every write operation received in the file appendonly.aof. This file will

# be read on startup in order to rebuild the full dataset in memory.

#

# Note that you can have both the async dumps and the append only file if you

# like (you have to comment the "save" statements above to disable the dumps).

# Still if append only mode is enabled Redis will load the data from the

# log file at startup ignoring the dump.rdb file.

#

# IMPORTANT: Check the BGREWRITEAOF to check how to rewrite the append

# log file in background when it gets too big.

#redis 默認每次更新操作后會在后臺異步的把數據庫鏡像備份到磁盤,但該備份非常耗時,且備份不宜太頻繁

#redis 同步數據文件是按上面save條件來同步的

#如果發生諸如拉閘限電、拔插頭等狀況,那么將造成比擬大范圍的數據丟失

#所以redis提供了另外一種更加高效的數據庫備份及災難恢復方式

#開啟append only 模式后,redis 將每一次寫操作哀求都追加到appendonly.aof 文件中

#redis重新啟動時,會從該文件恢復出之前的狀態.

#但可能會造成 appendonly.aof 文件過大,所以redis支持BGREWRITEAOF 指令,對appendonly.aof重新整理

appendonly no

# The name of the append only file (default: "appendonly.aof")

##更新日志文件名,默認值為appendonly.aof

# appendfilename appendonly.aof

# The fsync() call tells the Operating System to actually write data on disk

# instead to wait for more data in the output buffer. Some OS will really flush

# data on disk, some other OS will just try to do it ASAP.

#

# Redis supports three different modes:

#

# no: don't fsync, just let the OS flush the data when it wants. Faster.

# always: fsync after every write to the append only log . Slow, Safest.

# everysec: fsync only if one second passed since the last fsync. Compromise.

#

# The default is "everysec" that's usually the right compromise between

# speed and data safety. It's up to you to understand if you can relax this to

# "no" that will will let the operating system flush the output buffer when

# it wants, for better performances (but if you can live with the idea of

# some data loss consider the default persistence mode that's snapshotting),

# or on the contrary, use "always" that's very slow but a bit safer than

# everysec.

#

# If unsure, use "everysec".

#設置對 appendonly.aof 文件進行同步的頻率

#always 表現每次有寫操作都進行同步,everysec 表現對寫操作進行累積,每秒同步一次.

#no表現等操作系統進行數據緩存同步到磁盤,都進行同步,everysec 表現對寫操作進行累積,每秒同步一次

# appendfsync always

appendfsync everysec

# appendfsync no

# Virtual Memory allows Redis to work with datasets bigger than the actual

# amount of RAM needed to hold the whole dataset in memory.

# In order to do so very used keys are taken in memory while the other keys

# are swapped into a swap file, similarly to what operating systems do

# with memory pages.

#

# To enable VM just set 'vm-enabled' to yes, and set the following three

# VM parameters accordingly to your needs.

#是否開啟虛擬內存支持.

#redis 是一個內存數據庫,當內存滿時,無法接收新的寫哀求,所以在redis2.0后,提供了虛擬內存的支持

#但必要注意的,redis 所有的key都會放在內存中,在內存不夠時,只把value 值放入交換區

#雖使用虛擬內存,但性能基本不受影響,必要注意的是要把vm-max-memory設置到足夠來放下所有的key

vm-enabled no

# vm-enabled yes

# This is the path of the Redis swap file. As you can guess, swap files

# can't be shared by different Redis instances, so make sure to use a swap

# file for every redis process you are running. Redis will complain if the

# swap file is already in use.

#

# The best kind of storage for the Redis swap file (that's accessed at random)

# is a Solid State Disk (SSD).

#

# *** WARNING *** if you are using a shared hosting the default of putting

# the swap file under /tmp is not secure. Create a dir with access granted

# only to Redis user and configure Redis to create the swap file there.

#設置虛擬內存的交換文件路徑,不可多個Redis實例共享

vm-swap-file /tmp/redis.swap

# vm-max-memory configures the VM to use at max the specified amount of

# RAM. Everything that deos not fit will be swapped on disk *if* possible, that

# is, if there is still enough contiguous space in the swap file.

#

# With vm-max-memory 0 the system will swap everything it can. Not a good

# default, just specify the max amount of RAM you can in bytes, but it's

# better to leave some margin. For instance specify an amount of RAM

# that's more or less between 60 and 80% of your free RAM.

#設置開啟虛擬內存后,redis將使用的最大物理內存大小.

#默認為0,redis將把他所有能放到交換文件的都放到交換文件中,以盡量少的使用物理內存

#即當vm-max-memory設置為0的時候,其實是所有value都存在于磁盤

#在生產環境下,必要根據實際情況設置該值,最好不要使用默認的 0

vm-max-memory 0

# Redis swap files is split into pages. An object can be saved using multiple

# contiguous pages, but pages can't be shared between different objects.

# So if your page is too big, small objects swapped out on disk will waste

# a lot of space. If you page is too small, there is less space in the swap

# file (assuming you configured the same number of total swap file pages).

#

# If you use a lot of small objects, use a page size of 64 or 32 bytes.

# If you use a lot of big objects, use a bigger page size.

# If unsure, use the default :)

#設置虛擬內存的頁大小

如果 value 值比擬大,如要在 value 中放置博客、新聞之類的所有文章內容,就設大一點

vm-page-size 32

# Number of total memory pages in the swap file.

# Given that the page table (a bitmap of free/used pages) is taken in memory,

# every 8 pages on disk will consume 1 byte of RAM.

#

# The total swap size is vm-page-size * vm-pages

#

# With the default of 32-bytes memory pages and 134217728 pages Redis will

# use a 4 GB swap file, that will use 16 MB of RAM for the page table.

#

# It's better to use the smallest acceptable value for your application,

# but the default is large in order to work in most conditions.

#設置交換文件的總的 page 數量

#注意page table信息是放在物理內存中,每8個page 就會占據RAM中的 1 個 byte

#總的虛擬內存大小 = vm-page-size * vm-pages

vm-pages 134217728

# Max number of VM I/O threads running at the same time.

# This threads are used to read/write data from/to swap file, since they

# also encode and decode objects from disk to memory or the reverse, a bigger

# number of threads can help with big objects even if they can't help with

# I/O itself as the physical device may not be able to couple with many

# reads/writes operations at the same time.

#

# The special value of 0 turn off threaded I/O and enables the blocking

# Virtual Memory implementation.

#設置 VM IO 同時使用的線程數量.

vm-max-threads 4

# Hashes are encoded in a special way (much more memory efficient) when they

# have at max a given numer of elements, and the biggest element does not

# exceed a given threshold. You can configure this limits with the following

# configuration directives.

#redis 2.0后引入了 hash 數據結構.

#hash 中包括超過指定元素個數并且最大的元素當沒有超過臨界時,hash 將以zipmap來存儲

#zipmap又稱為 small hash,可大大減少內存的使用

hash-max-zipmap-entries 512

hash-max-zipmap-value 64

# Active rehashing uses 1 millisecond every 100 milliseconds of CPU time in

# order to help rehashing the main Redis hash table (the one mapping top-level

# keys to values). The hash table implementation redis uses (see dict.c)

# performs a lazy rehashing: the more operation you run into an hash table

# that is rhashing, the more rehashing "steps" are performed, so if the

# server is idle the rehashing is never complete and some more memory is used

# by the hash table.

#

# The default is to use this millisecond 10 times every second in order to

# active rehashing the main dictionaries, freeing memory when possible.

#

# If unsure:

# use "activerehashing no" if you have hard latency requirements and it is

# not a good thing in your environment that Redis can reply form time to time

# to queries with 2 milliseconds delay.

#

# use "activerehashing yes" if you don't have such hard requirements but

# want to free memory asap when possible.

#是否重置Hash表

#設置成yes后redis將每100毫秒使用1毫秒CPU時間來對redis的hash表重新hash,可降低內存的使用

#當使用場景有較為嚴格的實時性需求,不能接受Redis時不時的對哀求有2毫秒的延遲的話,把這項配置為no.

#如果沒有這么嚴格的實時性要求,可以設置為 yes,以便能夠盡可能快的釋放內存

activerehashing yes

Redis官方文檔對VM的使用提出了一些建議:

• 當key很小而value很大時,使用VM的效果會比擬好.因為這樣節約的內存比擬大

• 當key不小時,可以考慮使用一些非常辦法將很大的key變成很大的value,如可將key,value組合成一個新的value

• 最好使用linux ext3 等對稀疏文件支持比較好的文件系統保留你的swap文件

• vm-max-threads參數可設置拜訪swap文件的線程數,最好不要超過機器的核數；設置為0則所有對swap文件的操作都是串行的,可能會造成比較長時間的延遲,但是對數據完整性有很好的保證

redis數據存儲

redis的存儲分為內存存儲、磁盤存儲和log文件三部分,配置文件中有三個參數對其進行配置.

• save seconds updates,save配置,指出在多長時間內,有多少次更新操作,就將數據同步到數據文件.可多個條件配合,默認配置了三個條件.

• appendonly yes/no ,appendonly配置,指出是否在每次更新操作后進行日志記錄,如果不開啟,可能會在斷電時導致一段時間內的數據丟失.因為redis自己同步數據文件是按上面的save條件來同步的,所以有的數據會在一段時間內只存在于內存中.

• appendfsync no/always/everysec ,appendfsync配置,no表現等操作系統進行數據緩存同步到磁盤,always表現每次更新操作后手動調用fsync()將數據寫到磁盤,everysec表現每秒同步一次.
